DESCRIPTION
Concrete Renew™ is a one-component, polymer-modified, cementitious material for the resurfacing of existing
concrete to provide a like-new look to concrete surfaces.

FEATURES AND BENEFITS
▪ Improved formulation
▪ New, natural light gray color
▪ Easily installed from 1/16" to 1/8" (1.5 to 3 mm) per lift
▪ Can be finished by broom or trowel to resemble surrounding concrete
▪ Compatible with most sealers, dyes and stains
▪ Freeze/thaw stable
▪ Apply by trowel, broom, hopper gun or plaster pump
▪ Can be used with stencils to create a decorative system

WHERE TO USE
▪ Interior and exterior use
▪ Resurfacing of sound concrete surfaces
▪ Residential vehicle and pedestrian applications
▪ Textured “skip-trowel” finishes
▪ Dressing up worn concrete to provide a like-new finish

SUITABLE SUBSTRATES
▪ Concrete at least 28 days old
      Consult MAPEI’s Technical Services Department for installation recommendations                regarding substrates and conditions not listed.

SURFACE PREPARATION
▪ Concrete surfaces must be clean and free of loose particles, efflorescence, paints,                   tars, grease, asphaltic materials, bond breakers, curing compounds, wax, and any                 foreign substance or any conditions that may affect product performance or proper           bonding.
▪ Mechanically profile and prepare concrete surfaces by engineer-approved methods in           accordance with the most current ICRI 310.2R guidelines to obtain a concrete surface         profile (CSP) between #2 and #3.
▪ Ensure that the concrete substrate is saturated surface-dry (SSD) before installation of           Concrete Renew.
▪ Repair any concrete defects or spalls with either Mapecem Quickpatch, Planitop 18 ES,           or another approved MAPEI repair mortar. Reach out to your MAPEI technical                     representative for product recommendations. Refer to the respective products’ TDSs           for application instructions.
▪ Remove all the unsound and contaminated concrete. The substrate must have a pH of           10 or higher and a minimum tensile strength of 175 psi (1.21 MPa).
▪ Static cracks should be filled with a two-component epoxy resin such as Epojet™ [NA],            Epojet LV [NA] or another approved MAPEI epoxy resin. Reach out to your MAPEI                technical representative for product recommendations. MAPEI does not warrant that           cracks will not reappear, even when following established repair techniques.
▪ For porous substrates, apply a scrub coat created from a 3-to-1 ratio of water to                     Planicrete UA before applying Concrete Renew.

MIXING
Before product use, take appropriate safety precautions. Refer to the Safety Data Sheet (SDS) for details.
   1. One 25-lb. (11.3 kg) bag of Concrete Renew requires 2.39 U.S. qts. (2.26 L) of water.              For improved performance, replace the mixing water with 2.57 U.S. qts. (2.43 L) of                liquid created from a 3-to-1 ratio of water to Planicrete UA.
   2. Place 3/4 of the mixing liquid into a clean pail. Mix with a medium-speed drill (at 500          to 850 rpm) and a ribbon paddle.
   3. Slowly add Concrete Renew powder while mixing. While mixing, add the remaining             liquid to achieve the desired consistency.
   4. Mix for at least 2 minutes to a lump-free consistency.

PRODUCT APPLICATION
Read all installation instructions thoroughly before installation.
   1. For best results protect from wind and direct sunlight.
   2. If priming the prepared substrate, use a roller to apply a mixture with a 3-to-1 ratio of           water to Planicrete UA. Ensure that there are no puddles.
   3. Immediately apply a scrub coat of the mixed Concrete Renew to the prepared surface.
   4. Apply an initial coat of Concrete Renew to the desired thickness using either a trowel,         a hopper gun or a plaster pump.
   5. Finish the first coat to a brush finish or a light broom texture.
   6. After 3 hours apply the second coat, then finish the coat with a broom finish                       perpendicular to the previous layer.
   7. If a third coat is required repeat step 6.
   8. Apply a sealer as per the Curing section instructions.

EXPANSION AND CONTROL JOINTS
▪ Honor all expansion and control joints.
▪ Fill any saw-cut joints with a suitable joint sealant to protect against water intrusion               and freeze/thaw damage.

CURING
▪ Concrete Renew is self-curing.
▪ Concrete Renew should be sealed with a compatible water-based sealer within a few            hours of placement when temperatures are above 70°F (21°C). Apply Mapecure™ CS          WB for a glossy finish, or a silane-based sealer such as Planiseal WR 40 or Planiseal WR     100 to prevent efflorescence. Protect from dust and contaminants until the sealer                application.
▪ The sealer should be applied within 24 hours of the application of the final coating of           Concrete Renew.

PROTECTION
▪ Wait at least 1 hour before exposing to pedestrian traffic.
▪ Protect the fresh Concrete Renew from excessive heat, wind, and direct sunlight, which         could cause premature surface drying.
▪ Protect surrounding landscapes, hardscapes and structures during all phases of the               installation.

CLEANUP
▪ Wash hands and tools with water promptly before material hardens. Cured material               must be removed mechanically.

LIMITATIONS
▪ Do not install over substrates containing asbestos.
▪ Do not install over standing water or if rain is expected within the next 4 hours of the             installation.
▪ General application thickness should be no greater than 1/8" (3 mm) per lift.
▪ Two or more coatings of Concrete Renew are generally required. For applications on             substrates exposed to vehicular traffic always use diluted Planicrete UA mixed with             Concrete Renew and apply in three coats.
▪ Before application, test all surface treatments on a small sample area to ensure that the         desired results will be achieved.▪ Concrete Renew can be used for minor patching less         than 3/16" (4.5 mm) deep and 2" (50 mm) in diameter. Reduce the mixing liquid by            40% and mix to a stiff consistency.
▪ Verify compatibility before coloring with iron oxide pigments and liquid color packs.               Consult the manufacturer regarding proper use and dosages. Always perform a                   mock-up before application.
▪ Concrete substrate and ambient temperature must be between 45°F and 86°F (7°C and         30°C) before application. Temperatures must be maintained within this range for at             least 8 hours after the installation. Allow for extra curing time when temperatures are          below 65°F (18°C).
▪ Concrete Renew is not intended for use as an industrial wear surface or for heavy traffic.
▪ Do not mix more material than can be applied within 20 minutes.
▪ Do not re-temper or add more mix water. Remixing or adding more water will change           the final cured color.
▪ For applications subject to freeze/thaw conditions or beyond light residential use, always       mix Concrete Renew with a mixing liquid created from a 3-to-1 ratio of water to                 Planicrete UA.
▪ Do not expose Concrete Renew to rolling or dynamic loads for at least 24 hours after              installation.
▪ Do not allow Concrete Renew to bridge any moving expansion joint, crack and/or                  control joint.

Product Performance Properties*
Laboratory Tests Results

* mixed with water

Shelf Life and Product Characteristics
before mixing

Protect containers from freezing in transit and storage. Provide for heated storage on site and deliver all materials at least 24 hours before work begins.

Application Properties

CSI Division Classifications


Packaging

** Coverage shown is for estimating purposes only. Actual jobsite coverage may vary according to substrate conditions and setting practices.

ADDITIONAL INFORMATION
Refer to the Safety Data Sheet (SDS) for specific data related to health and safety as well as product handling.

For information on MAPEI’s commitment to sustainability and transparency, as well as how MAPEI products may contribute to green building standards and certification systems, contact sustainability-durabilite@mapei.com.

WARNING
The test results shown in the TECHNICAL DATA table were obtained in compliance with test methods and curing cycles, if applicable, defined in the industry standards referenced on the Technical Data Sheet. Please note that the use of test procedures or methods other than those indicated in the table could lead to different values and that, in such cases, any liability of our company is excluded.
